Ultra Long Range Wireless DVI Receiver

More Views

Ultra Long Range Wireless DVI Receiver

MPN:

GWLRDVIRX

UPC: 881317514707

MSRP: $199.95



600ft - Wireless DVI Receiver

The Ultra Long Range Wireless DVI Receiver is the latest addition to IOGEAR's extensive and award winning Wireless Video lineup. Wirelessly receive A/V signals from your source device such as PC or Blu-ray player via the wireless transmitters (GWLRHDTX for HDMI, GWLRDVITX for DVI, GWLRVGATX for VGA, all sold separately), located at never before possible distances of up to 600ft (183m) line of sight.


Versatile sources and displays combination

This wireless DVI receiver works with transmitters with HDMI output (GWLRHDTX, sold separately), VGA (GWLRVGATX, sold separately), or DVI output (GWLRDVITX, sold separately). ** Ideal for application with mixed sources.



Cut the Cord and Cut the Cost

With support for HD resolutions up to 1080p, you can cut the video cords without sacrificing picture quality paired with a transmitters with various input (GWLRHDTX for HDMI, GWLRDVITX for DVI, GWLRVGATX for VGA, all sold separately). Enjoy a stunning video experience with the convenience of wireless and the flexibility to network your environment the way you want without investing in expensive wiring. Effectively eliminate cable clutter and transmit powerful long range digital signals across wide open spaces, up to 600ft. No need to run expensive video cables at long distances.


HDMI Receiver for Multiple Applications

IOGEAR's Ultra Long Range Wireless DVI Receiver is ideal for digital signage and applications where A/V signals need to be transmitted long distances such as restaurants, retail stores, airports, houses of worship, concerts, sporting events and venues.

*IR is only supported between receivers and transmitter with HDMI connection, will not support receivers and transmitters with VGA or DVI connections.
**Only video is transmitted with DVI receivers or transmitters.

  • Receives High Definition Video from up to 600ft away
  • Supports resolutions of up to 1080p @ 60fps
  • Plug-N-Play solution
  • Mix & Match between DVI, HDMI and VGA transmitters
  • Perfect for retail and commercial applications
  • Display
  • Display or Projector with DVI Input
  •
  • Media Source
  • 1 HDMI, DVI or VGA Output
  •

Note: GWLRDVITX is required for sources with DVI output; GWLRHDTX is required for sources with HDMI output, GWLRVGATX is required for sources with VGA output.

  • 1 x Ultra Long Range Wireless Receiver with DVI
  • 1 x DVI Cables
  • 1 x Power Adapter
  • 1 x Quick Start Guide
  • 1 x Warranty Card
FunctionGWLRDVIRX
Connectors
Power1 x Power Jack
Video Resolution1920x1080@60Hz;1680x1050@60Hz;1440x900@60Hz; 1360x768@60Hz;1280x1024@60Hz;1280x960@60Hz; 1280x720@60Hz;1024x768@60Hz;800x600@60Hz
Video Streaming<200ms Latency H.264
Frequency5GHz
Antenna TypeDual High Gain 5 DBi
Operating RangeUp to 600 ft
Housing
CaseMetal
Power
Amps3 A
Voltage5 V
Power Consumption< 10 W
Operating Temperature32 - 140 F
Humidity10 - 95% Non-Condensing
Warranty1 Year
Video connections
OutputDVI-D 1.0
DimensionsGWLRDVIRX
Unit Dimensions
Height1.75 in
Depth4.50 in
Length7.63 in
Unit Package Dimensions
Width10.25 in
Height6.25 in
Depth3.75 in
Master Carton
Width11 in
Height14.50 in
Depth13 in
Master Carton Qty.6
Weight
Master Carton Wt.16.25 lb
Unit Wt. w/accessories2.50 lb
Unit Wt.1.40 lb
